Introduction

Learn about the fundamentals of Active Directory Domain Services (AD DS) in Windows Server, including forests, domains, sites, domain controllers, organizational units (OUs), users, and groups.

Learning objectives

After completing this module, you’ll be able to:

Describe AD DS.
Describe users, groups, and computers.
Identify and describe AD DS forests and domains.
Describe OUs.
Manage objects and their properties in AD DS.

Prerequisites

To get the best learning experience from this module, you should have knowledge and experience of:

Windows Server.
Core networking technologies.

Active Directory Domain Services (AD DS) :

A Microsoft directory service that acts as a central repository for enterprise networks, managing identities, resources, and access control. It simplifies administrative tasks by providing a secure, searchable hierarchy for organizing users, computers, and groups.

The logical framework of AD DS is built on a hierarchy of components: Schema: The blueprint. It defines the exact rules, object types, and attributes (e.g., user account fields, passwords) that can be created in the directory.

Component	Description	Hierarchical Level	Namespace Relationship	Key Function
Domain	A logical, administrative container for grouping resources and security boundaries.	Mid-Level	Maps directly to a portion of the database.	Groups resources and applies security policies.
Organizational Unit (OU)	Sub-containers within a domain are used to organize objects.	Lowest-Level	Shares the parent domain’s namespace.	Organizes objects and delegates administrative control to departments/locations.
Domain Tree	A hierarchical grouping of domains.	Mid-to-High Level	Shares a continuous, contiguous namespace (e.g., company.com and sales.company.com).	Connects domains with a trust relationship and shared namespace.
Forest	The highest-level logical container in AD DS.	Highest-Level	Can contain multiple trees that do not share a contiguous namespace.	Shares a common schema, configuration, and Global Catalog across all domain trees.
Partition	Specific portions of the AD DS database.	Database-Level	N/A	Breaks the database into categories (Schema, Configuration, Domain) for replication.

The following table describes some of the physical components of AD DS.

Physical Component	Concise Description
Domain Controller (DC)	A server containing a copy of the AD DS database; processes and replicates changes across the domain.
Data Store	The Ntds.dit file and logs (default: C:\Windows\NTDS) using Microsoft Jet technology to store directory info.
Global Catalog (GC) Server	A DC hosting a partial, read-only copy of all forest objects to speed up cross-domain searches.
Read-Only Domain Controller (RODC)	A special AD DS installation for low-security locations or branch offices; does not allow direct database changes.
Site	A container for objects specific to a physical location, used to manage network traffic and replication topology.
Subnet	A range of IP addresses assigned to computers within a specific site; a single site can contain multiple subnets.

user objects:

In AD DS, you must provide all users that require access to network resources with a user account. With this user account, users can authenticate to the AD DS domain and access network resources.
In Windows Server, a user account is an object that contains all the information that defines a user. A user account includes:
The username.
A user password.
Group memberships.
A user account also contains settings that you can configure based on your organizational requirements.
The username and password of a user account serve as the user’s sign-in credentials. A user object also includes several other attributes that describe and manage the user. You can use the following to create and manage user objects in AD DS:
Active Directory Administrative Center.
Active Directory Users and Computers.
Windows Admin Center.
Windows PowerShell.

The dsadd command-line tool.

· Define AD DS forests and domains:

An AD DS forest is a collection of one or more AD DS trees that contain one or more AD DS domains. Domains in a forest share:
A common root.
A common schema.
A global catalog.
An AD DS domain is a logical administrative container for objects such as:
Users
Groups
Computers
What is an AD DS forest?
A forest is a top-level container in AD DS. Each forest is a collection of one or more domain trees that share a common directory schema and a global catalog. A domain tree is a collection of one or more domains that share a contiguous namespace. The forest root domain is the first domain that you create in the forest.
The forest root domain contains objects that don’t exist in other domains in the forest. Because you always create objects on the first domain controller, a forest can consist of as few as one domain with a single domain controller, or it can consist of several domains across multiple domain trees.
The following graphic displays Contoso.com as the forest root domain. Beneath are two domains, Adatum.com in a separate tree, and Seattle.Contoso.com as a child of Contoso.com.
The following objects exist in the forest root domain:
The schema master role.
The domain naming master role.
The Enterprise Admins group.
